Description
| Main configuration | Item | Configuration | Main technical parameters | Item | Parameters | |
| Control Form | Handlebar type | Length×Width×Height(mm) | 3000×1100×1750 (40-foot high cube container fits 34 units of CKD) | |||
| Windshield Wiper | Single wiper (auto reset) | |||||
| Braking Form | Drum brakes: front 130, rear 180 | Minimum Ground Clearance | 150MM | |||
| Body Material | Pressed steel shell | |||||
| Motor | Permanent magnet synchronous/AC asynchronous scheme | Minimum Turning Radius(m) | 4 | |||
| Controller | Permanent magnet synchronous/AC asynchronous scheme | Wheelbase(mm) | 2280 | |||
| Rear Axle | Direct drive rear axle | Track Width(mm) | 990 | |||
| Instrument | Ordinary LCD instrument panel | Number of Rows of Seats | 3 | |||
| Multimedia | USB port, SD, radio, Bluetooth audio | Number of Occupants | 6 | |||
| Shock Absorber | Front: hydraulic outer spring, rear: trailing arm suspension | Gross Vehicle Weight(kg) | 310 | |||
| Wheel Hub | 4.00-12 steel rim | Maximum Payload(kg) | 700 | |||
| Tire | 4.00-12 steel wire 6P tire, three wheels interchangeable | Charging Time | 6-8 | |||
| Canopy | Boned awning frame | Top Speed(km/h) | 40-70 | |||
| Braking Method | Mechanical one-foot three brakes | Braking Distance(m) | 8 | |||
| Parking Method | Hand brake parking, P gear | Gear Ratio | First gear: reduction ratio 10:1/8:1 Second gear: fast 10:1/slow 24:1 Second gear (small): fast 10:1/slow 20:1 | |||
